FEATURES:
-Quality construction
-Built on a solid cast iron frame.
-Cast iron blade wheels with rubber tires for traction are mounted
on shafts with taper roller bearings.
-Large cast iron work tables tilt right and left and front and back.
-Infinitely variable speeds allows you to select the most efficient speed (FPM) for each piece quickly and easily.
-Blade welder, will weld blades up to the saw capacity.
-Fully adjustable blade guide support for workpieces of varying thicknesses.
COMPLETE WITH:
Bandsaw blade
Built-in blade welder with grinder wheel
Work Light
Chip blower
Manual
SPECIFICATIONS
Blade Size: 159-1/2" x 1/8"-1"
Blade Speed: (Var.) 82 to 1,496 FPM
Cutting Capacity: (Height) 14-1/2"
Cutting Capacity: (Width) 20"
Dimensions: 78" x 32" x 46"
Motor: 1.5 KW (2 HP)
MACHINE WIRED FOR 230 VOLTS 3 PH
Table Height: 39"
Table Size: 29-1/8" x 26-3/4"
Table Tilt: 15°
NEW PRICE PER KBC WEBSITE: $9,300.00
*SPECIFICATIONS TAKEN FROM KBC WEBSITE AND SHOULD BE VERIFIED
