Swivel saw head allows miter cutting from 0° to 60°
Hydraulic cylinder plus precision ground hinge support
Hardened worm gear for durability
Hard stops at 0°, 45°, and 60° for quick angle set-up
Capacity:
0°:Round: 13″
Rectangular: 11″ x 17.3″
+45°:Round: 11.8″Rectangular: 11″ x 9.4″
+60°:Round: 8.6″Rectangular: 9.4″ x 8.6″
Coolant Tank Capacity: 7.9 Gallons
Hydraulic Tank Capacity: 2.08 Gallons
Blade Speed: 60Hz: 75, 117, 166, 47 FPM
Blade Size (LxWxT): 13' 7" x 1" x .035"
Blade Motor: 3 HP
Coolant Motor: 1/8 HP
Workbed Height: 32.3"
Weight: 2,079 lbs
Floorspace (LxWxH): 74" x 107" x 82"
Weight: approx. 1,980 lbs.Blade drive equipped with variable pulley system
Adjustable flood coolant system
Motor-driven, synchronized wire blade brush
Carbide blade guides and bearing provides additional blade support
Rigid cast-iron guide arms
Cast-iron hydraulic vise
Adjustable down feed control
Adjustable material stop
Saw head automatically raises after each cut
