DEMO SAMSTAR 20" X 40" FLAT BED CNC LATHE

Swing Over Bed 20"
Swing Over Carriage 12"
Max. Length Of Workpiece 40"
Max. Stroke Of Slide 10"
Spindle Bore Dia. 2.8"
Range of Spindle Speeds (12) 40-1800 RPM
Longitudinal Feed 0-236 Inch/Min.
Cross Feed 0-118 Inch/Min.
Range Of Thread & Pitch 0.5-12 MM,
2.125-50.8 TPI
Main Motor (2 Speed) 8.7/10.6 HP
Power (Volts/Phase/Cycle 220 V/3PH/60Hz
Tailstock Taper #5 Morse Taper
PLEASE SEE BROCHURE AND PRICE SHEET ATTACHED FOR COMPLETE SPECIFICATIONS AND OPTIONAL EQUIPMENT

** WE RESERVE THE RIGHT TO CHANGE DESIGN, COLOR, SPECIFICATIONS, OR PRICE WITHOUT NOTICE **
