USED SAMSTAR 39" x 9" COLUMN RADIAL DRILL
Have one to sell?
ConditionUsed
1 available
*SPECIFICATIONS WERE TAKEN FROM MANUFACTURERS BROCHURE AND SHOULD BE VERIFIED.
MAXIMUM DIAMETER DRILLED 1 3/4 cast 1 1/2 steel
DISTANCE BETWEEN COLUMN & SPINDLE 39"
DISTANCE FROM SPINDLE TO BASE 40"
TAPER IN SPINDLE (MORSE) #4
QUILL DIAMETER 2 3/4"
SPINDLE TRAVEL 11"
SPINDLE SPEEDS (16 CHANGES) 32 to 2500 RPM
SPINDLE FEEDS (8 CHANGES) 0.10 - 1.250 IPM
DIAMETER OF COLUMN 9"
LENGTH OF ARM 39"
BOX TABLE SIZE 23 1/2"x 17 1/2" x17 1/2"
MAIN MOTOR 3 HP
APROXIMATE OVERALL DIMENSIONS 68" X 32" X 94"
NET APPROXIMATE WEIGHT 4,500 LBS.
MAXIMUM DIAMETER DRILLED 1 1/2 cast 1 1/4 mild steel
BOX TABLE 23 1/2"x 17 1/2" x17 1/2"
WORK LIGHT
COOLANT SYSTEM 1/6 HP
POWER ELEVATION 1 HP
POWER CLAMPING ON COLUMN 1/2 HP
Can be seen under power on our showroom floor!!
