Maximum capacity: Straight Cut (90°) 14 in. x 14 in.
Maximum capacity: At a 45° Angle 9 in. x 14 in.
Standard length gauge 0 to 20 in.
Overall 20-1/4 in.
Receiving side 9-3/8 in.
Cut-off side 10-7/8 in.
Height - Floor To Vise Table 29-1/8 in.
Speed range - approx. strokes per minute 3 speeds 50-85-125
Length of stroke 6 in.
Overall size 32" F-B 74" L 73" H
Length of saw blade* 18 in. or 21 in.
Motor 5 H.P. 230v 3ph
Approximate Weight 4000 lbs.
Coolant System
1-3/4 in. Wide Blade
